Bench-Top Type Temperature (& Humidity) Chamber

Share to:

Premium features for the ultimate in testing flexibility
two sizes: 0.8 & 2.2 cubic feet
High temperature to 150°C
Low temp to -20, -40, or -60°C
0.8 cu.ft. models are our smallest chambers
Fully programmable via touch-screen

Quantity:

Product Description


Small Temperature Test Chamber
Premium features for the ultimate in testing flexibility

Are you looking for the smallest chamber possible to get your testing done? Hate the footprint and noise of other temperature chambers? Need to closesly integrate other test equipment? These are the temperature chambers for you!

Small Temperature Test Chamber Easy to install and own:
The models are small enough be placed underneath a benchtop, or on top.
Designed for integration with other test equipment to make a complete test stand.
The smaller models run on standard 115V power, enabling easy installation anywhere.
Extremely quiet operation as low as 52 dba, suitable for quiet labs or offices.

Small Temperature Test Chamber CHAMBER DESIGN FEATURES:
.Premium design with a space-saving footprint and quiet operation suitable for offices and small labs
.One 1" diameter cable port on the right side (Note: previous model series also included standard port on left)
.One adjustable stainless steel shelf
.Temperature output terminals

Small Temperature Test Chamber SAFETY FEATURES:
.Three levels of overheat protection
.Specimen power supply control terminal


Small Temperature Test Chamber Specification:



 ModelSMC-22-CCSMC-27-CCSMC-64-CC
Temperature Temperature range-60℃~180℃
(A:0℃~180℃;B:-20℃~180℃;C:-40℃~180℃;D:-60℃~180℃)
Temperature fluctuation±0.5℃
Cooling rate180.0℃~-60.0℃  Within about 100 minutes 1.0~3.0℃/min
Heating rate-60.0℃~180.0℃ Within about 60 minutes 3.0~5.0℃/min
Temperature uniformity±1.0℃ (-40.0℃~100.0℃)
±1.5℃ (100.1℃~180.0℃or-40.0℃~-60.0℃)
HumidityHumidity range20.0%RH~98.0%RH
Humidity fluctuation±1.0% RH
Humidity uniformity±2.0%RH
MaterialInternal materialSUS304 stainless steel(1.2mm)
External materialcold-rolled plate(1.2mm),powder coating
Heat insulationpolyurethane foam(100mm)+glass wool(10mm)
FanCentrifugal fan(Impeller Fan)
Refrigeration compressorhermetic compressor(Tecumseh)
Cooling modeair cooling
RefrigerantR404A、R23、R508
Evaporatorfinned-tube exchanger
Heaternickel chrome strip heater
HumidifierSteam Humidifier
Size Interior(mm)  W*H*D300 X 300 X 250 22.5L300 X 300 X 300 27L 400 X 400 X 400 64L
Exterior(mm) W*H*D500X850X1150500X 850X1190600X950X1350
Weight85kg105kg105kg
Working Temperature+5 ~ 35℃
Power supply220V/AC   50/60Hz 12A 220V/AC   50/60Hz 23A220V/AC   50/60Hz 23A
ControllerStandard: South Korea TEMI-1500
Optional: South Korea TEMI-2500,South Korea TEMI-2700


Product Catalog:

Bench-Top Type Temperature (& Humidity) Chamber.pdf

Please consult the sales for specific technical parameters, SANWOOD reserves the right of explanation.
