Salt Spray Environmental Cyclic Corrosion Test Machine

Views:40     Author:Site Editor     Publish Time: 2018-04-27      Origin:Site

    Salt Spray Environmental Cyclic Corrosion Test Machine Salt Spray Tester



1. Application


Salt Spray Environmental Cyclic Corrosion Test Machine are designed to be flexible enough to comply with as many different CCT specifications as possible.

As standard they come with the ability to create 4 distinct climatic.


  • Wetting mode;

  • Salt Spray mode;

  • Drying mode;

  • Controlled humidity mode;


2. Technology Parameters


Model SM-Y-010 SM-Y-016 SM-Y-020
Internal dimensions (mm) 770*1430*700 800*1900*850 800*2100*850
Overall dimensions (mm) 1450*2520*1620 1350*3000*1700 1650*3200*1700
Technical structure
Temperature range +10℃ ~ +110℃
Humidity range 30% ~ 98% RH
Temperature tolerance ±2.0 ℃
Humidity tolerance +2%,-3%
Salt concentration tolerance ±1%
Spray deposition 1~2ml / 80cm2 · h
Spray type Continuous / Periodic
Temperature Controller Programmable color touch display controller
Interior /Exterior material Glass fiber reinforced plastics;
Sealing Hydrostatic hood seal
Power Supply 380V 50HZ Three-phase five little system



Salt Spray Environmental Cyclic Corrosion Test Machine Salt Spray Tester



3. Salt Spray Environmental Cyclic Corrosion Test Machine
